COLNAGO V3RS DISC FRAMESET

COLNAGO V3RS DISC FRAMESET  The Colnago V3Rs Disc Frameset is an incredibly lightweight and fast frame made to build a dominant road bike that will thrive in all situations. This new version shows...
Ordered on demand
Size*
Color*
RZBW
RZGR
RZRD
RZWB
$6,300.00

COLNAGO V3RS DISC FRAMESET

The Colnago V3Rs Disc Frameset is an incredibly lightweight and fast frame made to build a dominant road bike that will thrive in all situations. This new version shows improvement in all areas compared to the highly praised VR-1 and VR-2 models. The VR3s is known for its ability to perform in all road situations including long stage races, Gran Fondos, training days, and anything in between. This bike is incredibly smooth on pavement but can also take on tougher terrain like gravel. With dropped seatstays and an aero tube profile, this frame features the best of Colnago technology.

This monocoque carbon frame is the lightest disc frame that has ever hit the road for the V3Rs. At just 790g at size 50, the Colnago V3Rs is engineered to maximize the ratio of performance and comfort. These improvements are achieved through the use of a new type of carbon fiber with adds 12 percent more rigidity at the rear triangle and 6 percent at the head tube compared to the V2-R. This carbon construction also provides great absorption of vertical shocks, leading to a more comfortable ride on all terrain. The lightweight monocoque carbon of the V3Rs Disc is ready to fly up climbs, sprint on flat ground, or take on long and technical day of riding.

A lightweight frame is always a plus, but a geometry that adds to a reliable ride is just as important. Excellent aerodynamic properties pair with unprecedented lightness to create reliable speed regardless of the situation. A lowered bottom bracket improves the drivability and stability of the V3Rs. A shorted head tube and a longer fork. The new fork is longer than the V2-r version at just 390g uncut. An integrated steerer is included and the fork can hold tires up to 30mm wide. The seatpost closure reduces the weight of the locking system and increases the functionality, power, and safety of the system. The new version utilizes a D-shaped seatpost like the race-ready C64. With integrated cable routing, a clean and sleek frame which is more aerodynamic. The Colnago V3Rs is here to help riders take on any day of road riding.

COLNAGO V3RS DISC FRAMESET SPECIFICATIONS

  • Bottom Bracket Type Press-Fit 86 Required
  • Frame Material T800 Carbon, 12x142mm Thru-Axle
  • Fork Colnago Carbon, 12x100mm Thru-Axle
  • Headset Tapered Headset 1-1/8" to 1-1/4"
  • Seatpost Colnago V3-RS Carbon
  • Front Derailleur Type Braze-On Required
*Specifications are subject to change.

COLNAGO V3RS DISC FRAMESET GEOMETRY / SIZE CHART

Bike Geometry
Size Seat Tube (c-c) Seat Tube (c-t) Top Tube Length Head Tube Length Chain Stay Length Seat Tube Angle Head Tube Angle Stand Over Height Wheel Size Stack Reach
42 - 420 501 113 408 75.5 70.6 - 700c 514 368
45 - 450 514 114 408 75.0 71.0 - 700c 520 375
48 - 480 526 117 408 74.5 71.5 - 700c 525 380
50 - 500 537 132 410 74.0 71.6 - 700c 542 382
52 - 520 549 151 410 73.6 71.9 - 700c 560 384
54 - 540 565 168 414 73.1 72.5 - 700c 578 390
56 - 560 579 175 414 73.0 72.9 - 700c 586 400
58 - 580 593 193 414 73.0 73.1 - 700c 604 408

FRAME SPECIFICATIONS

  • Frame: Colnago V3Rs Monocoque Carbon 12 x 142mm Rear Thru-Axle, ThreadFit 82.5 BB, internal cable routing (790g, size 50)
  • Fork: 1 1/8 – 1 1/4” tapered straight blade carbon disc, 12 x 100mm Thru-Axle, 1 1/8 – 1 1/4"
  • Headset: Colnago Integrated headset
  • Seatpost: Colnago Aero Seatpost with included seat collar
