Sold Out
COLNAGO C64 FROZEN EDITION
COLNAGO C64 FROZEN EDITION DISC
The flagship model in the renowned Italian brand's range, the Colnago C64 Frozen Edition Disc Integrated Frameset is completely hand-built in Italy, and hand-paint...
Ordered on demand
COLNAGO C64 FROZEN EDITION DISC
The flagship model in the renowned Italian brand's range, the Colnago C64 Frozen Edition Disc Integrated Frameset is completely hand-built in Italy, and hand-painted in a striking frozen edition design pattern. The Colnago C64 Frozen Edition In Canada is built on the iconic lugged construction of its refined C60 predecessor is retained, and the finest carbon is used to create the frame and fork, this model being the lightest, stiffest and most comfortable in the 'C' range to date. Changes include a unidirectional carbon finish, a single piece seat tube and seat lug, and a redesigned fork, alongside an update to the material of the headset for better vibration damping and a reshaped downtube that creates a more balanced shaping to the frame.
Still designed for a ThreadFit82.5 bottom bracket, the cable guide is now moulded to the lug, improving shifting performance thanks to the larger radius. This Colnago C64 Frozen Edition frameset could make the perfect core for your dream build, be that for racing or as your Sunday best. It's highly compatible, both with mechanical and electronic groupsets and offering the clearance for wider 28mm tyres, with the integrated design of the brake cabling keeping the aesthetics incredibly clean.
COLNAGO C64 FROZEN DISC FRAMESET SPECIFICATIONS
- Bottom Bracket Type Threadfit82.5 – BB86 Required
- Frame Material High Modulus Carbon
- Fork Colnago C64, 1 1/4″-1 1/8″, Internal Cable Routing
- Headset Colnago Integrated, 1/8″ to 1 1/4″
- Seatpost Colnago C64 Carbon
- Front Derailleur Type Braze-On Required
*Specifications are subject to change.
COLNAGO C64 DISC FRAMESET GEOMETRY / SIZE CHART
| Size | Seat Tube (c-c) | Seat Tube (c-t) | Top Tube Length | Head Tube Length | Chain Stay Length | Seat Tube Angle | Head Tube Angle | Stand Over Height | Wheel Size | Stack | Reach |
|---|---|---|---|---|---|---|---|---|---|---|---|
| 42 | 420 | 532 | 510 | 115 | 405 | 75.49 | 70.8 | – | 700c | 515 | 377 |
| 45 | 450 | 540 | 520 | 118 | 405 | 75.14 | 71.15 | – | 700c | 522 | 381 |
| 48 | 480 | 548 | 530 | 122 | 408 | 74.58 | 71.52 | – | 700c | 528 | 383 |
| 50 | 500 | 570 | 540 | 141 | 410 | 74.00 | 71.62 | – | 700c | 548 | 383 |
| 52 | 520 | 589 | 550 | 158 | 410 | 73.57 | 71.92 | – | 700c | 565 | 384 |
| 54 | 540 | 610 | 565 | 175 | 412 | 72.83 | 72.49 | – | 700c | 583 | 385 |
| 56 | 560 | 619 | 582 | 182 | 414 | 72.75 | 72.88 | – | 700c | 591 | 398 |
| 58 | 580 | 637 | 594 | 199 | 414 | 72.75 | 73.12 | – | 700c | 608 | 405 |
| 60 | 600 | 657 | 605 | 219 | 414 | 72.75 | 73.3 | – | 700c | 628 | 410 |
